SP-HDMI KVM Extender 20KM (1920×1080P)
The SP-HDMI KVM Extender 20KM is an ultra-long-distance HDMI + USB signal transmission solution built for professional-grade environments. Using advanced single-mode fiber optic technology, it delivers uncompressed Full HD 1080p video, embedded HDMI audio, and responsive KVM control (keyboard/mouse) over distances up to 20 kilometers without any signal loss or degradation.
Key Features
- Extends HDMI video and USB KVM control up to 20km over single-mode fiber.
- Supports maximum resolution of 1920×1080p @ 60Hz (Full HD).
- Uncompressed video transmission with 165MHz / 4.95Gbps total bandwidth.
- HDMI embedded audio support for clear sound.
- USB ports for keyboard, mouse, and select USB peripherals.
- Durable metal enclosure for EMI shielding and heat dissipation.
- Plug-and-play setup — no software or drivers required.
Recommended Applications
- Remote control rooms and monitoring stations
- Broadcast studios and media production facilities
- Industrial and manufacturing control systems
- Security and surveillance operations
Specifications
| Item | Specification |
|---|---|
| Model | SP-HDMI KVM Extender 20KM (1920×1080P) |
| Maximum Resolution | 1920×1080p @ 60Hz (Full HD) |
| Transmission Distance | Up to 20km over single-mode fiber optic cable |
| Signal Type | HDMI + USB (KVM control) |
| Video Bandwidth | 165MHz / 1.65Gbps per channel (4.95Gbps total) |
| Audio Support | HDMI embedded audio |
| USB Support | Keyboard, mouse, and select USB peripherals |
| HDCP Compliance | Yes |
| Connectors | HDMI Input / Output USB Type-A for devices USB Type-B for host Single-mode LC fiber optic port |
| Fiber Mode | Single-mode, 9/125μm |
| Wavelength | 1310nm or 1550nm (depending on model) |
| Power Supply | DC 5V (included) |
| Material | Metal enclosure for durability and EMI shielding |
| Operating Temperature | 0°C ~ 60°C |
| Installation | Plug-and-play, no drivers required |
