Shieldplus
SP- CAT-7 SFTP CABLE -305M- COPPER
SP- CAT-7 SFTP CABLE -305M- COPPER
Regular price
Rs. 24,780.00
Regular price
Sale price
Rs. 24,780.00
Unit price
per
Taxes included.
Couldn't load pickup availability
The SP-SFTP CAT-7 Cable – 305M is a high-speed, high-shielded Ethernet cable designed for next-generation networking environments requiring ultra-fast data transmission with superior protection against interference. Built with 100% pure copper conductors, the cable uses Skin-Foam-Skin (SFS) insulation for excellent dielectric strength and signal integrity. Each twisted pair is individually shielded with foil (FTP) and the entire cable is protected with a braided shield (S) to deliver exceptional performance in electrically noisy environments. Ideal for data centers, high-performance computing, industrial automation, and future-ready networks.
| Feature | Specification |
| Brand | SP (Shield Plus) |
| Cable Category | CAT-7 |
| Cable Type | S/FTP (Shielded Foiled Twisted Pair) |
| Conductor Material | 100% Pure Bare Copper |
| Conductor Size | 23 AWG (0.57mm ± 0.005mm) |
| Number of Pairs | 4 Twisted Pairs (8 Conductors) |
| Insulation Type | Skin-Foam-Skin (SFS) Polyolefin |
| Pair Shielding | Individual Aluminium Foil Shield |
| Overall Shielding | Braided Aluminium / Tinned Copper Mesh |
| Jacket Material | LSZH or PVC (Indoor Use) |
| Cable Length | 305 Meters (1000 Feet) |
| Bandwidth Support | Up to 600 MHz |
| Data Transmission Rate | Up to 10 Gbps (10GBASE-T Ethernet) |
| Compliance Standards | ISO/IEC 11801 Class F, EN 50288-4-1, IEC 61156-5 |
| Operating Temperature | -20°C to +60°C |
| Flame Rating | IEC 60332-1, RoHS Compliant |
| Packaging | Wooden Reel or Pull Box (Optional) |
| Color | Blue/Grey / Black (Customizable) |
